Products NVR Lite-N 1HDD H.265 1 HDD 5ch Mini NVR
H.265 1 HDD 5ch Mini NVR
H.265 1 HDD 5ch Mini NVR H.265 1 HDD 5ch Mini NVR

H.265 1 HDD 5ch Mini NVR

Tiandy
اشتراک گذاری
TC-R3105
Spec: I/B/L/(Eu)
__________________________________
• Up to 5-channel input
• Up to 6MP Resolution Recording
• Incoming Bandwidth 50Mbps
• Outgoing Bandwidth 40Mbps
محصولات مرتبط

HD Input

• S+265/H.265/H.264 video formats

• Connectable to the third-party network cameras

• Support live view, storage, and playback of the connected camera at up to 6MP resolution

HD Output

• HDMI and VGA simultaneous output

• HDMI Video output at up to 4K (3840x2160) resolution

HD Storage

• 1 SATA interface, up to 8TB for 1 HDD

• S+265 compression effectively reduces the storage space and costs by up to 75%

HD Transmission

• 1×RJ45 self-adaptive 10/100 Mbps network interface

Various Applications

• Centralized management of IP cameras, including configuration, information import/export, real-time information display, upgrade, etc.

• Connectable to smart IP cameras from Tiandy and the recording, playing back, and backing up of VCA alarms can be realized

• VCA detection alarm is supported

• Web6 supports plug-in free browsing and can preview videos on all browsers

• Support cloud upgrade



Input
Video Input 5-ch
Max Resolution 6MP
Two-way Audio Input N/A
Bandwidth Income 50Mbps; Outgoing 40Mbps

Output
HDMI/VGA Output HDMI 1-ch, 3840x2160, 1920×1080, 1280×720, 1024×768, 1366×768, 1440×900, 1280×800
VGA 1-ch, 1920×1080, 1280×720, 1024×768, 1366×768, 1440×900, 1280×800
Screen Split 1/3/4/5
Audio Output N/A

Decoding
Decoding Format S+265/H.265/H.264
Recording Resolution 6MP/5MP/4MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Preview Capability 1×6MP, 1×5MP, 1×4MP, 1×3MP, 4×1080P, 5×720P, 5×4CIF
Synchronous Playback 1×6MP, 1×5MP, 1×4MP, 1×3MP, 3×1080P, 4×720P
Records Encryption Yes

Hard Disk
SATA 1 SATA interface for 1 HDDs
Capacity Up to 8TB for each HDD
eSATA Interface N/A
Array Type N/A

External Interface
Network Interface 1xRJ45 self-adaptive 10/100 Mbps network interface
USB Interface 2xUSB 2.0
Serial Interface N/A
Alarm In/Out N/A

Network
Protocol TCP/IP, ICMP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, IGMP, QoS, IPV4, IPV6, Multicast, ARP, UDP, Telnet, RTMP
System Compatibility ONVIF (PROFILE S/T), SDK, P2P

General
Web Version Web6
Language Traditional Chinese, English
Operating Conditions -10℃～55℃, 10%~90% RH
Power Supply DC12V 1.5A
Consumption (without HDD)  ≤10W (without HDD)
Chassis 1U
Dimensions

42.9×200×199.5mm, (1.69×7.87×7.85 inch)
Weight (without HDD) 0.4Kg (0.88lb)
